Connection to one or more MTConnect agents
Make Machine-Tool Data Available Through OPC UA
Connect MTConnect-enabled CNC machines and manufacturing equipment to OPC UA-based monitoring, analytics, MES, SCADA, and enterprise applications.
MTConnectMachine-Tool Data
OPC UAStandard Interface
UnifiedShopfloor Visibility
MTConnect OPC UA Server
The MayilVeera MTConnect OPC UA Server bridges machine information exposed by MTConnect agents with applications that consume OPC UA data. It reads the MTConnect device model and observations, maps the available information into an OPC UA address space, and provides a common interface for downstream applications.
It is intended for machine-tool monitoring, production visibility, maintenance analysis, and manufacturing-system integration.
Logical Architecture
A website-level view of how the product connects sources, processing layers, diagnostics, and destination systems.
CNC Machines and Machine Tools
01
MTConnect Agents
Device ModelSamplesEventsConditions
02
HTTP / HTTPS
03
MTConnect Connector
Agent DiscoveryParsingHealth Monitoring
04
Semantic Mapping and Conversion
ComponentsData ItemsTypesUnitsTimestamps
05
OPC UA Server Layer
Address SpaceSessionsSecurityDiagnostics
OPC UA Applications
MESSCADAHMIHistorianAnalyticsIIoT Platform
Key Capabilities
Retrieval of device models and machine observations
Mapping of MTConnect devices, components, and data items
OPC UA address-space generation
Timestamp and data-quality preservation
Machine-specific mapping configuration
Connection-health and data-freshness monitoring
Diagnostic logging
Controlled exposure of selected machine information
Integration with OPC UA client applications
How It Works
The document flow is presented as an implementation-style process so visitors can understand the operating path quickly.
- 01
The product connects to configured MTConnect agents.
- 02
It retrieves the device model and available data items.
- 03
MTConnect components, events, samples, and conditions are mapped to OPC UA objects and variables.
- 04
Machine observations are updated in the OPC UA address space.
- 05
OPC UA clients browse and subscribe to the required machine information.
- 06
Agent connection, data age, and mapping issues are reported through diagnostics.
Applications
Where It Fits
CNC machine monitoring
Machine-state and utilisation visibility
Production-status dashboards
Downtime and stoppage analysis
Tool and spindle data collection, when exposed by the machine
Condition and alarm monitoring
MES and historian integration
Multi-machine data normalisation
Manufacturing analytics
Brownfield machine-data integration
Benefits
Practical Benefits
Connects MTConnect machine data with a broader range of OPC UA applications
Reduces one-off machine-data interfaces
Preserves the structured relationship between machines, components, and data items
Supports consistent integration across compatible machine tools
Creates a reusable data interface for production and maintenance systems
Integration and Deployment
A machine survey should identify the MTConnect agent endpoints, supported standard version, device model, accessible data items, update frequency, network security, and expected consuming applications.
Machine-specific terminology and optional data items may require a mapping exercise before commissioning.
Reliability and Security
Agent-connection monitoring
Data-age and stale-data indication
Controlled reconnection
Parsing and mapping diagnostics
HTTPS support where implemented
OPC UA certificate-based communication where supported
Access control for the OPC UA endpoint
Configuration backup and audit trail, where implemented
Need Help Selecting the Right Product?
Equipment and controller make or model
Required interfaces, protocols, channels, or tag count
Operating environment and target platform
Update rate, cycle time, delivery schedule, and custom engineering needs
Do not publish price, availability, certification, warranty, protocol, electrical rating, capacity, performance, or compatibility statements until they are linked to the exact shipping SKU or software version.
Frequently Asked Questions
Does it create data that is not available through MTConnect?
No. It can map and organise available machine information, but the source machine or MTConnect agent must expose the required data.
Will every CNC machine expose the same information?
No. Available components and data items depend on the machine, controller, adapter, and MTConnect agent configuration.
Can it support production analytics?
It can supply structured machine data to analytics applications. The resulting KPIs depend on data availability, production context, and agreed calculations.
Connect MTConnect Machines to Your OPC UA Environment
Share the agent endpoint, device-model sample, required data items, number of machines, network arrangement, and target applications for a compatibility assessment.
